LED Pepperl Fuchs Safety Barrier Vt18 8 H 120 M 40a 65b 118 128 Diffuse Mode Sensor Flashing

Name: LED Pepperl Fuchs Safety Barrier Vt18 8 H 120 M 40a 65b 118 128 Diffuse Mode Sensor Flashing
Brand: Achievers Automation Limited
SKU: VT18-8-H-120-M/40A/65B/118/128
Availability: InStock

Brand Name:	PEPPERL FUCHS
Model Number:	VT18-8-H-120-M/40A/65B/118/128
MOQ:	1
Price:	Negotiable
Delivery Time:	Negotiable
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Germany

Manufacturer:

PEPPERL FUCHS

Product No:

VT18-8-H-120-M/40A/65B/118/128

Detection Range Max:

0 ... 400 Mm

Light Source:

LED

Mission Time (TM):

20 A

Switching Voltage:

30 V DC

Switching Frequency:

500 Hz

Packaging Details:

carton

Supply Ability:

100pcs per month

Highlight:

LED Diffuse Mode Pepperl Fuchs Safety Barrier

400MM Pepperl Fuchs Safety Barrier

vt18 8 h 120 m 40a 65b 118 128

Product Description

PEPPERL FUCHS VT18-8-H-120-M/40A/65B/118/128 Diffuse mode sensor Flashing power on LED in case of short-circuit

Ambient light limit 30000 Lux
Hysteresis H < 15 %
Functional safety related parameters
MTTFd 700 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %
Indicators/operating means
Operation indicator LED green, flashes in case of short-circuit
Function indicator LED yellow, lights up with receiver lit
Control elements Sensing range adjuster, light-on/dark-on changeover switch
Electrical specifications
Operating voltage UB 10 ... 30 V DC , class 2
Ripple 10 %
No-load supply current I0 < 30 mA
Protection class II , rated voltage ≤ 50 V AC with pollution degree 1-2 according to IEC 60664-1
Output
Switching type light/dark on, switchable
Signal output Push-pull output, short-circuit protected, reverse polarity protected
Switching voltage 30 V DC
Switching current max. 200 mA
Switching frequency f 500 Hz
Response time 1 ms
Conformity
Product standard EN 60947-5-2
Approvals and certificates
CE conformity yes
EAC conformity TR CU 020/2011
UL approval cULus Listed, Type 1 enclosure
CCC approval CCC approval / marking not required for products rated ≤36 V
Ambient conditions
Ambient temperature-25 ... 70 °C (-13 ... 158 °F)
Storage temperature-30 ... 70 °C (-22 ... 158 °F)
Mechanical specifications
Degree of protection IP67
Connection 4-pin, M12 x 1 connector
Material
Housing brass, nickel-plated
Optical face PMMA
Mass 60 g

LED Pepperl Fuchs Safety Barrier Vt18 8 H 120 M 40a 65b 118 128 Diffuse Mode Sensor Flashing 0
