| Brand Name: | p&f |
| Model Number: | IPT1-FP |
| MOQ: | 1 |
| Price: | Negotiable |
| Delivery Time: | Negotiable |
| Payment Terms: | T/T |
The Pepperl+Fuchs IPT1-FP is a low-frequency 125 kHz read/write station designed for industrial RFID applications. It features an integrated control interface and can be configured for various serial or fieldbus communication options such as PROFIBUS DP. Built to IP67 standards, this compact device offers a read distance of up to 100 mm and is engineered for reliable operation in harsh industrial environments.
| Property | Value |
| Product Type | RFID Read/Write Station |
| Frequency | 125 kHz (Low Frequency) |
| Functionality | Read and Write |
| Read Range | Up to 100 mm |
| Write Range | Up to 50 mm |
| Data Interface | Integrated control interface |
| Property | Value |
| Housing Material | PBT Plastic |
| Connection Type | M12 Connector |
| Protection Class | IP67 |
| Operating Temperature | -25 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Dimensions (W x H x D) | 50 mm x 50 mm x 35.5 mm |
| Property | Value |
| Supply Voltage | 24 V DC (±20%) |
| Current Consumption | ≤ 100 mA |
| Communication Options | PROFIBUS DP, RS232, RS422, RS485 |
| Data Transfer Rate | Configurable, e.g., 9600 to 115200 baud (serial) |
| Status Indicators | LED for power and communication |
| Programmable Parameters | Yes (e.g., baud rate, data bits, parity) |
