| Brand Name: | p&f |
| Model Number: | KCD2-UT2-Ex1 |
| MOQ: | 1 |
| Price: | Negotiable |
| Delivery Time: | Negotiable |
| Payment Terms: | T/T |
The Pepperl+Fuchs KCD2-UT2-Ex1 is an ultrasonic sensor specifically engineered for precise distance measurement and object detection within hazardous locations. It carries ATEX and IECEx certifications, ensuring safe and reliable operation in potentially explosive atmospheres. With its robust housing and high immunity to environmental interference, this compact sensor delivers dependable performance in a wide range of demanding industrial applications.
| Property | Value |
| Attribute Category | Description |
| Product Model | KCD2-UT2-Ex1 |
| Product Category | Temperature Signal Conditioner |
| Brand | Pepperl+Fuchs |
| Key Function | Converts RTD, thermocouple, potentiometer, or voltage signals from hazardous areas to 0/4-20 mA |
| Safety Integrity Level | SIL 2 according to IEC/EN 61508 / IEC/EN 61511 |
| Explosion Protection | Certified for use in explosive atmospheres (IECEx BAS 13.0057X) |
| Property | Value |
| Attribute Category | Description |
| Power Supply | 24 V DC (via power rail or terminals 9+, 10-) |
| Rated Voltage | 19 ... 30 V DC |
| Power Consumption | ≤ 0.98 W |
| Analog Output | 0/4...20 mA |
| Output Mode | Sink or source mode selectable |
| Load | 0...550 Ω (source mode) |
| Property | Value |
| Attribute Category | Description |
| Supported Input Types | Thermocouples (Types B, E, J, K, etc.), RTDs (Pt100, Pt1000, etc.) |
| Connection Methods | 2-wire, 3-wire, or 4-wire connection for RTDs |
| Measurement Current (RTD) | Approx. 200 μA |
| Lead Resistance (RTD) | Max. 50 Ω per line |
| Cold Junction Compensation | External and internal (for thermocouples) |
| Diagnostics | Line fault detection (LFD), sensor burnout detection |
Achievers Automation Limited is a well-established player in the field of industrial automation with over 12 years of experience. The company provides a comprehensive range of industrial automation components and instruments to customers in over 45 countries worldwide.
